规格Specifications
|
两顶针距离 |
Distance between centers |
450/ 700mm |
|
回转直径 |
Swing over bed |
250mm |
|
中拖板行程 |
Swing over cross slide |
115mm |
|
主轴锥孔 |
Taper of spindle bore |
MT4 |
|
主轴通孔 |
Spindle bore |
27mm |
|
主轴转速级数 |
Step of spindle speeds |
6 |
|
主轴转速范围 |
Range of spindle speeds |
115-1620rpm |
|
车削英制螺纹 |
Range of inch threads |
8-56T.P.I |
|
车削公制螺纹 |
Range of metric threads |
0.2 -3.5mm /r |
|
尾座锥度 |
Taper of tailstock quill |
MT3 |
|
电机 |
Main Motor |
750W |
|
包装尺寸 |
Packing size |
1260/1510×570×580mm |
|
机床净重 |
Net weight |
151kg / 171kg |
随机附件Standard Accessories
|
名称 |
Name |
QTY |
|
三角卡盘 |
Three-Jaw Chuck |
1pc |
|
三角皮带 |
V-belt |
1pc |
|
呆顶针 |
Dead Centers |
2pc |
|
内六角扳手 |
Wrench |
1pc |
|
呆扳手 |
Spanner |
1sets |
|
挂轮 |
Change Gears |
1pc |
|
刀架扳手 |
Wrench for tool post |
1pc |
********************************************************************************************************************************
